How to get different color for different branches in a plot in MatLab, Mathematica and Desmos

I am trying to obtain slab-waveguide dispersion plot like this (dashed line): I tried following code in Matlab:

function main fimplicit (@(x,y)f(x,y),[0 10]) end function fun = f(x,y) nc=1.45; %cladding nf=1.5; ns=1.4; %substrate h=5; %width of waveguide beta=sqrt(x^2*nf^2-y.^2); gammas=sqrt(beta.^2-x^2*ns^2); gammac=sqrt(beta.^2-x^2*nc^2); z=sin(h*y); %TE mode fun=z-cos(h*y)*(gammac+gammas)./(y-gammas.*gammac./y); end

What I got:

Using Desmos:

Using Mathematica:

nc = 1.45; nf = 1.5; ns = 1.4; h = 5; ContourPlot[ Sin[h y]*(y^2 - (Sqrt[x^2*(nf^2 - nc^2) - y^2]* Sqrt[x^2*(nf^2 - ns^2) - y^2])) == Cos[h y]*(Sqrt[x^2*(nf^2 - nc^2) - y^2] + Sqrt[x^2*(nf^2 - ns^2) - y^2])*y, {x, 0, 10}, {y, 0.1, 10}]

All the plots are in excellent agreement with form expected. However the original plot has a different color for each branch, how can I implement this in MatLab, Desmos or Mathematica ?

1 Answer

Mathematica

Update

Add legend, use darker yellow color.

colors = {Blue, Green, Red, Cyan, Magenta, RGBColor["#cdcd41"]}; labels = MapThread[ ToString[Subscript[Style["TE", Bold, 16, #2], Style[ToString@#1, Bold, 12, #2]], StandardForm] &, {Range[0, 5], colors}]; legend = LineLegend[colors, labels, LegendLayout -> "ReversedColumn", LegendMarkerSize -> 20]; plot = ContourPlot[ Sin[h y]*(y^2 - (Sqrt[x^2*(nf^2 - nc^2) - y^2]* Sqrt[x^2*(nf^2 - ns^2) - y^2])) == Cos[h y]*(Sqrt[x^2*(nf^2 - nc^2) - y^2] + Sqrt[x^2*(nf^2 - ns^2) - y^2])*y, {x, 0, 10}, {y, 0, 4}, PlotLegends -> legend]; coloredLines = Riffle[colors, Cases[plot, _Line, Infinity]]; plot /. {a___, Repeated[_Line, {6}], c___} :> {a, Sequence @@ coloredLines, c}

Original answer

I could not find a way to use ContourPlot options to color the lines of an implicit function plot. Here is a way (hack) to do it by post processing the plot expression.

plot = ContourPlot[ Sin[h y]*(y^2 - (Sqrt[x^2*(nf^2 - nc^2) - y^2]* Sqrt[x^2*(nf^2 - ns^2) - y^2])) == Cos[h y]*(Sqrt[x^2*(nf^2 - nc^2) - y^2] + Sqrt[x^2*(nf^2 - ns^2) - y^2])*y, {x, 0, 10}, {y, 0, 4}]; coloredLines = Riffle[{Blue, Green, Red, Cyan, Magenta, Yellow}, Cases[plot, _Line, Infinity]]; plot /. {a___, Repeated[_Line, {6}], c___} :> {a, Sequence @@ coloredLines, c}
