I am converting an integrated webcam from an old Asus X52J laptop into an USB webcam but the colors of the wiring kinda threw me off.
Here's a couple of images:
How do i match them to a standard black-red-green-white USB cable?
Webcam part no. is 04g620008630 0420-006a000 11261025542 1211
3 Answers
SOLUTION:
It is a 5V camera but the polarity is inverted:
- (USB cable) <---> (Webcam)
- RED (+5v) <---> BLACK
- BLACK (GND) <---> ORANGE
- WHITE (D+) <---> BROWN
- GREEN (D-) <---> RED
- nothing <---> YELLOW
Then it gets correctly detected:
usb 2-1.2: new high-speed USB device number 7 using ehci-pci usb 2-1.2: New USB device found, idVendor=13d3, idProduct=5130 usb 2-1.2: New USB device strings: Mfr=2, Product=1, SerialNumber=0 usb 2-1.2: Product: USB 2.0 Camera usb 2-1.2: Manufacturer: Sonix Technology Co., Ltd. Linux video capture interface: v2.00 uvcvideo: Found UVC 1.00 device USB 2.0 Camera (13d3:5130) input: USB 2.0 Camera as /devices/pci0000:00/0000:00:1d.0/usb2/2-1/2-1.2/2-1.2:1.0/input/input27 usbcore: registered new interface driver uvcvideo USB Video Class driver (1.1.1) grzywomat's answer is accurate (D+ and D- are swapped) but this seems to need 3.3V, I did it was straight 5v and it got quite hot, I put a 3.3V regulator on it and it doesn't get too hot anymore.
Actually for me the order of data pins is the other way round, i.e. standard for USB. Nevertheless thank you, as your identification was very helpful. (After soldering as per your schematics, I decided to reverse data pins, as power draw seemed fine (power pins not terribly wrong), and dmesg returned some “cannot enumerate” message which looked to me like just data pins being wrong..)
